TurTle - Hydrostatic Pressure Transmitter
TurTle – Hydrostatic Pressure Transmitter is developed directly for the water and sewerage industry
The TurTle - Hydrostatic Pressure Transmitter
with it´s replaceable measurement cell
ACOWA’s TurTle stands out as a revolutionary pressure transmitter, often referred to as a level sensor. Notably, it is recognized by its robust design – developed specifically for the wastewater industry.
A key advantages of the TurTle, is its unique measurement cell that can be separated from the sensor housing which is constructed in AISI304 stainless steel. In other words, the measurement cell can be replaced without actually having to replace the entire electrical installation. This also applies in the case of a damaged cable, where the measurement cell can be reused in another sensor housing.
Adjustable range of measurement with TurTle
Another of TurTle’s remarkable features lies in its measurement range which is adjustable when using a DIP switch – located at the rear of the measurement cell. TurTle can measure in 3 ranges, 0-3m, 0-5m or 0-10m, all with 4-20mA output signal. Notably, the measurement cell can be zero-calibrated using the DIP switch.
Besides its measurement features, TurTle includes a PUR-cable which has the following standard lengths:10m, 15m, 30m or 50m.
Precision and durability with TurTle - Hydrostatic Pressure Transmitter
Above all, the TurTle uses a ceramic capacitive measurement cell with long durability, stability and great precision. The sensor’s capillary tube is equipped with a filter that prevents absorption of moisture. It has a total weight of 1.3 kg, which makes it incredibly stable in conditions with turbulent water.
Read more about the TurTle
Lastly, for more info about the TurTle in a country near you, go to our agent page/turtle
Additionally, for danish speaking people – feel free to visit wasys.dk/turtle/
SPECIFICATIONS
Length | 235mm |
Largest diameter | 50mm |
Weight | 1300g with 10m cable and measuring cell |
Wire connection | Red = Supply, Green = Signal, Black = Screen |
Cable length | 10m, 15m or 30m. |
Free fall drop | 30 cm |
Enclosure class | IP68 |
Power Supply | 24V DC (10V DC – 28V DC) |
Max. overpressure | 6 bar |
Measuring range | 0-3m, 0-5m or 0-10m in the same sensor head |
Measurement signal | 4-20 mA |
Measurement principle | Ceramic capacitive |
Accuracy | Better than 0,25% of FS |
Long-term stability | Better than 0,5% of FS per year |
Sensor head | Impact resistant PP (Fiberglass 30%) |
Cable housing | AISI 304 |
Cable clamp | 0-3m, 0-5m or 0-10m in the same sensor head |
Operating temperature | -20°C tio+85°C |
Certificates | CE |
Product number | Description |
---|---|
1772-2202010 | TurTle level sensor |
1772-2201010 | Sensor housing for measuring cell with 10m PUR cable |
1772-2201015 | Sensor housing for measuring cell with 15m PUR cable |
1772-2201030 | Sensor housing for measuring cell with 30m PUR cable |
The TurTle level sensor is highly versatile and used in numerous applications, such as:
- Pumping stations
- Sewage treatment plants
- Stormflow
- Level monitoring
- Rivers or streams
- Reservoir and tanks
